| Management features |
|---|
| Multicast support | Yes |
| Switch layer | L2 |
| Switch type | Managed |
| System event log | Yes |
| MIB support | MIB-II |
| Ports & interfaces |
|---|
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-LX, 1000BASE-SX, 1000BASE-T |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 2 |
| Network |
|---|
| IGMP snooping | Yes |
| Networking standards | IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af |
| Number of VLANs | 4096 |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-LX, 1000BASE-SX, 1000BASE-T |
| VLAN support | Yes |
| Port mirroring | Yes |
| IP routing | Yes |
| Auto MDI/MDI-X | Yes |
| 10G support | No |
| Virtual LAN features | Tagged VLAN |
| Virtual LAN features |
|---|
| Number of VLANs | 4096 |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN |
| Data transmission |
|---|
| Number of VLANs | 4096 |
| MAC address table | 8000 entries |
| Switching capacity | 20 Gbit/s |
| Jumbo frames support | Yes |
| Security |
|---|
| Security algorithms | 802.1x RADIUS, HTTPS, SNMP, SSH |
| IGMP snooping | Yes |
| DHCP features | DHCP client, DHCP relay, DHCP snooping |
| Multicast features |
|---|
| Multicast support | Yes |
| Design |
|---|
| Product colour | Black |
| LED indicators | LAN, PoE |
| Certification | FCC Class A, ICES Class A, CE (EMC Class A, LVD, RoHS), C-Tick, VCCI Class A, UL cUL, TUV/GS, CB, Mexico UL DGN notification, WEEE, REACH, BSMI, KCC/MSIP, ANATEL |
| Performance |
|---|
| Internal memory | 256 MB |
| Flash memory | 32 MB |
| Mean time between failures (MTBF) | 548553 h |
| Harmonized System (HS) code | 85176990 |
| Technical details |
|---|
| Harmonized System (HS) code | 85176990 |
| Power |
|---|
| Power consumption (max) | 73.3 W |
| Power supply included | Yes |
| Input current | 1.2 A |
| DC input voltage | 54 V |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 55 W |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Heat dissipation | 249.5 BTU/h |
| Weight & dimensions |
|---|
| Width | 240 mm |
| Depth | 27 mm |
| Height | 105 mm |
| Weight | 640 g |
