| Data transmission |
|---|
| Firewall throughput | 1000 Mbit/s |
| VPN throughput | 360 Mbit/s |
| IPS/IDS throughput | 636 Mbit/s |
| Maximum firewall connections per second | 9500 |
| Maximum firewall connections | 1300000 |
| Branch Office VPN | 40 |
| Performance |
|---|
| Syslog | Yes |
| Concurrent connections | 1300000 |
| Mean time between failures (MTBF) | 499632 h |
| Certification | WEEE, RoHS, ICSA, NRTL/C, CB |
| Network |
|---|
| Number of users | 200 user(s) |
| Number of VLANs | 75 |
| DHCP server | Yes |
| DHCP client | Yes |
| Security |
|---|
| Security algorithms | 3DES,128-bit AES,192-bit AES,256-bit AES,802.1x RADIUS,DES,MD5,SHA-1,SSL/TLS |
| Firewall security | DoS, HTTP, HTTPS, SMTP, FTP, DNS, TCP, POP3, SIP, H.323 |
| VPN support | IPSec, SSL, L2TP |
| Protocols |
|---|
| Management protocols | SNMP v2/v3 |
| Supported network protocols | IPv6 |
| Management features |
|---|
| LED indicators | Yes |
| Web-based management | Yes |
| Ports & interfaces |
|---|
| Connectivity technology | Wired |
| Gigabit Ethernet (copper) ports quantity | 5 |
| USB 2.0 ports quantity | 2 |
| WAN connection | Ethernet (RJ-45) |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 5 |
| Power |
|---|
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1.2 A |
| Power supply | 15 W |
| Number of power supply units | 1 |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 4570 m |
| Weight & dimensions |
|---|
| Dimensions (WxDxH) | 205.5 x 217 x 48 mm |
