| Power |
|---|
| On/off switch | Yes |
| AC input voltage | 100-240 V |
| Power consumption (typical) | 25 W |
| Power consumption (max) | 60 W |
| Data transmission |
|---|
| Firewall throughput | 3400 Mbit/s |
| VPN throughput | 880 Mbit/s |
| IPS/IDS throughput | 510 Mbit/s |
| Maximum firewall connections per second | 18000 |
| Branch Office VPN | 30 |
| Firewall (UDP 1518) throughput | 3.4 Gbit/s |
| Firewall (IMIX) throughput | 1 Gbit/s |
| VPN (UDP 1518) throughput | 0.88 Gbit/s |
| VPN (IMIX) throughput | 272 Mbit/s |
| HTTPS encryption | Yes |
| Gateway antivirus throughput | 0.623 Gbit/s |
| Current connections (proxy) | 200000 |
| TDR host sensors capacity | 20 |
| Performance |
|---|
| Reset button | Yes |
| Built-in processor | Yes |
| Processor frequency | 1000 MHz |
| Processor cores | 4 |
| Concurrent connections | 500000 |
| Mean time between failures (MTBF) | 157751 h |
| Certification | WEEE, FCC
CAN/CSA C22.2 No.60950-1-07, 2nd ed.
 2014-10
UL 60950-1, 2nd ed. 2014-10-14
IEC 60950-1:2005+A1:2009+A2:2013
IEC 62368-1: 2014 2nd ed.
EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 |
| Processor architecture | ARM Cortex-A53 |
| Network |
|---|
| Point-to-point protocol over Ethernet (PPPoE) | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
| Networking standards | IEEE 802.1Q,IEEE 802.3ad |
| Quality of Service (QoS) support | Yes |
| Number of VLANs | 50 |
| DHCP server | Yes |
| DHCP client | Yes |
| Dynamic routing | Yes |
| Dynamic DNS (DDNS) | Yes |
| Mobile VPN tunnels quantity | 30 |
| Security |
|---|
| Security algorithms | FIPS 140-2, TLS |
| Protocols |
|---|
| Routing protocols | BGP,OSPF,RIP |
| Management features |
|---|
| On/off switch | Yes |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Connectivity technology | Wired & Wireless |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 5 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Memory |
|---|
| Internal memory type | DDR4 |
| Internal memory | 4096 MB |
| Storage |
|---|
| Storage media type | SSD |
| SSD capacity | 16 GB |
| Technical details |
|---|
| Sustainability compliance | Yes |
| Sustainability certificates | RoHS |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 10 - 85% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 4570 m |
| Weight & dimensions |
|---|
| Weight | 900 g |
| Width | 203.2 mm |
| Depth | 215.9 mm |
| Height | 43.2 mm |
| Packaging data |
|---|
| Package width | 308 mm |
| Package height | 261 mm |
| Package depth | 181 mm |
| Package weight | 1.86 kg |
