| Power |
|---|
| On/off switch | Yes |
| AC input voltage | 100-240 V |
| Power consumption (typical) | 24 W |
| Data transmission |
|---|
| Firewall throughput | 1700 Mbit/s |
| Maximum firewall connections per second | 8500 |
| Branch Office VPN | 10 |
| Firewall (UDP 1518) throughput | 1.7 Gbit/s |
| Firewall (IMIX) throughput | 0.51 Gbit/s |
| VPN (UDP 1518) throughput | 0.485 Gbit/s |
| VPN (IMIX) throughput | 0.14 Mbit/s |
| Gateway antivirus throughput | 0.328 Gbit/s |
| UTM throughput (fast/full scan) | 0/0.154 Gbit/s |
| IPS throughput (fast/full scan) | 0/0.271 Gbit/s |
| TDR host sensors capacity | 5 |
| Performance |
|---|
| Reset button | Yes |
| Concurrent connections | 100000 |
| Mean time between failures (MTBF) | 1101388 h |
| Certification | CC EAL4+, FIPS 140-2, NRTL/CB, IPv6 Ready Gold, WEEE |
| Network |
|---|
| Point-to-point protocol over Ethernet (PPPoE) | Yes |
| Networking standards | IEEE 802.1Q, IEEE 802.3ad |
| Quality of Service (QoS) support | Yes |
| Number of VLANs | 10 |
| DHCP server | Yes |
| DHCP client | Yes |
| Dynamic routing | Yes |
| Dynamic DNS (DDNS) | Yes |
| Mobile VPN tunnels quantity | 10 |
| Security |
|---|
| Security algorithms | HTTPS, TLS |
| Firewall security | DoS attacks, fragmented & malformed packets, blended threats |
| DDoS protection | Yes |
| Stateful Packet Inspection (SPI) | Yes |
| Management features |
|---|
| On/off switch | Yes |
| LED indicators | Yes |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Connectivity technology | Wired |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 5 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Technical details |
|---|
| Sustainability compliance | Yes |
| Sustainability certificates | REACH, RoHS |
| Harmonized System (HS) code | 85176990 |
| Software |
|---|
| Bundled software | 3-yr Basic Security Suite |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 10 - 85% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 4570 m |
| Weight & dimensions |
|---|
| Weight | 880 g |
| Width | 203.2 mm |
| Depth | 215.9 mm |
| Height | 43.2 mm |
| Packaging data |
|---|
| Package width | 308 mm |
| Package height | 261 mm |
| Package depth | 181 mm |
| Package weight | 1.86 kg |
| Packaging content |
|---|
| Bundled software | 3-yr Basic Security Suite |
