| Performance |
|---|
| Full duplex | Yes |
| 2.4 GHz | No |
| 5 GHz | Yes |
| Maximum data transfer rate | 5400 Mbit/s |
| Ethernet LAN data rates | 100,1000,2500,10000 Mbit/s |
| Frequency band | 57 - 71 GHz |
| Web-based management | Yes |
| Reset button | Yes |
| Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, QPSK |
| Certification | FCC, IC |
| Operating system installed | AirOS |
| Internal memory | 512 MB |
| Built-in processor | Yes |
| Processor frequency | 1400 MHz |
| Features |
|---|
| 6 GHz | No |
| Full duplex | Yes |
| 2.4 GHz | No |
| 5 GHz | Yes |
| Maximum data transfer rate | 5400 Mbit/s |
| Ethernet LAN data rates | 100,1000,2500,10000 Mbit/s |
| Frequency band | 57 - 71 GHz |
| Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, QPSK |
| Throughput data rate | 2700 Mbit/s |
| Operating system installed | AirOS |
| Internal memory | 512 MB |
| Built-in processor | Yes |
| Processor frequency | 1400 MHz |
| Security |
|---|
| Security algorithms | AES, WPA2-PSK |
| Protocols |
|---|
| Management protocols | SNMP |
| Management features |
|---|
| Web-based management | Yes |
| Ports & interfaces |
|---|
| WAN connection | Ethernet (RJ-45) |
| Ethernet LAN (RJ-45) ports | 1 |
| Power |
|---|
| Power consumption (max) | 24 W |
| Output current | 0.65 A |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | Passive PoE |
| DC voltage range | 48 V |
| Design |
|---|
| Placement | Wall |
| International Protection (IP) code | IPX6 |
| Housing material | Aluminium, Polycarbonate (PC) |
| Reset button | Yes |
| LED indicators | Yes |
| Product colour | White |
| Certification | FCC, IC |
| Antenna |
|---|
| Antenna type | Internal |
| Polarization | Vertical polarization |
| Antenna gain level (max) | 24 dBi |
| Technical details |
|---|
| Sustainability compliance | Yes |
| Sustainability certificates | CE |
| Weight & dimensions |
|---|
| Width | 212 mm |
| Depth | 187 mm |
| Height | 205 mm |
| Weight | 2.3 kg |
| Packaging data |
|---|
| PoE adapter included | Yes |
| Number of products included | 1 pc(s) |
| Packaging content |
|---|
| PoE adapter included | Yes |
| Number of products included | 1 pc(s) |
| Other features |
|---|
| Wireless standard | 802.11ax (WiFi 6) |
| Polarization | Vertical polarization |
| Operational conditions |
|---|
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 60 °C |
| Sustainability |
|---|
| Sustainability compliance | Yes |
| Sustainability certificates | CE |
