All stock codes associated to this product
RNUC13ANKI30000, 5732517, II356145, 5032037267182
| Motherboard |
|---|
| Motherboard form factor | UCFF |
| Processor |
|---|
| Built-in processor | Yes |
| Processor model | i3-1315U |
| Processor boost frequency | 4.5 GHz |
| Processor threads | 8 |
| Processor family | Intel ® Core™ i3 |
| Processor cores | 6 |
| Processor manufacturer | Intel |
| Processor codename | Raptor Lake |
| CPU configuration (max) | 1 |
| Processor cache | 10 MB |
| Performance cores | 2 |
| Efficient cores | 4 |
| Performance-core boost frequency | 4.5 GHz |
| Efficient-core boost frequency | 3.3 GHz |
| Processor generation | Intel Core i3-13xxx |
| Memory |
|---|
| Memory voltage | 1.2 V |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Supported memory types | DDR4-SDRAM |
| Supported memory clock speeds | 3200 MHz |
| Memory channels | Dual-channel |
| Maximum internal memory | 64 GB |
| ECC | No |
| Non-ECC | Yes |
| Number of DIMM slots | 2 |
| Video |
|---|
| Graphics card family | Intel |
| On-board graphics card | No |
| Storage |
|---|
| Supported storage drive types | SSD |
| Storage drive sizes supported | M.2 |
| Storage drive interface | PCI Express, Serial ATA |
| Number of storage drives supported | 2 |
| SSD form factor | M.2 |
| NVMe | Yes |
| Graphics |
|---|
| Maximum resolution | 7680 x 4320 pixels |
| Graphics card family | Intel |
| On-board graphics card | No |
| Number of displays supported | 4 |
| On-board graphics card model | Intel Iris Xe Graphics |
| Audio |
|---|
| Intel ® High Definition Audio (Intel ® HD Audio) | Yes |
| Built-in speaker(s) | No |
| Network |
|---|
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| LAN controller | Intel I226-V |
| Bluetooth version | 5.3 |
| Bluetooth | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Ports & interfaces |
|---|
| Number of SATA III connectors | 1 |
| Serial port via internal header | No |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Combo headphone/mic port | Yes |
| USB 2.0 ports quantity | 1 |
| HDMI version | 2.1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPorts quantity | 1 |
| DC-in jack | Yes |
| M.2 card slot (wireless) | 2230 (E-key) (E) |
| USB ports quantity | 4 |
| M.2 card slot (storage) | 2280 NVMe (M); 2242 SATA (B) |
| Thunderbolt 4 ports quantity | 2 |
| Expansion slots |
|---|
| PCI Express slots version | 4.0 |
| Number of M.2 (M) slots | 1 |
| Design |
|---|
| Motherboard form factor | UCFF |
| Product type | Mini PC barebone |
| ARK ID | 233095 |
| On/off switch | Yes |
| LED indicators | Yes |
| Cooling type | Active |
| Product colour | Black |
| Chassis type | UCFF |
| Product family | Intel NUC |
| Product codename | Arena Canyon |
| Status | Launched |
| Performance |
|---|
| Windows operating systems supported | Windows 10 IoT Enterprise, Windows 11 x64 |
| Linux operating systems supported | RedHat EL Linux, Y |
| Motherboard form factor | UCFF |
| Maximum resolution | 7680 x 4320 pixels |
| Operating system installed | No |
| Number of displays supported | 4 |
| Compatible operating systems | Windows 10 IoT Enterprise*|Ubuntu*|Linux* |
| Harmonized System (HS) code | 8471500150 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| Software |
|---|
| Operating system installed | No |
| Compatible operating systems | Windows 10 IoT Enterprise*|Ubuntu*|Linux* |
| Processor special features |
|---|
| Intel ME Firmware Version | 16.1 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Flex Memory Access | Yes |
| Execute Disable Bit | Yes |
| Intel ® Optane™ Memory Ready | No |
| Intel ® High Definition Audio (Intel ® HD Audio) | Yes |
| Intel ® AES New Instructions (Intel ® AES-NI) | Yes |
| Embedded options available | No |
| Intel ® Platform Trust Technology (Intel ® PTT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Colour |
|---|
| Product colour | Black |
| Power |
|---|
| DC input voltage | 12 - 20 V |
| Power supply type | External AC adapter |
| Technical details |
|---|
| Intel ® High Definition Audio (Intel ® HD Audio) | Yes |
| Intel ® AES New Instructions (Intel ® AES-NI) | Yes |
| Embedded options available | No |
| Cooling type | Active |
| Chassis type | UCFF |
| Harmonized System (HS) code | 8471500150 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| ARK ID | 233095 |
| Indication |
|---|
| LED indicators | Yes |
| Management features |
|---|
| On/off switch | Yes |
| Features |
|---|
| Number of displays supported | 4 |
| Logistics data |
|---|
| Harmonized System (HS) code | 8471500150 |
| Weight & dimensions |
|---|
| Width | 117 mm |
| Depth | 112 mm |
| Height | 37 mm |
| Other features |
|---|
| Embedded options available | No |
| DC input voltage | 12 - 20 V |
| Chassis type | UCFF |
| Additional headers | Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby); Internal 2x2 power connector |
| Launch date | Q1'23 |
Intel ® Virtualization Technology for Directed I/O (VT-d) Intel ® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium ® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel ® Virtualization Technology (VT-x) Intel ® Virtualization Technology (VT-x) allows one hardware platform to function as multiple "virtual" platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel ® AES New Instructions Intel ® AES New Instructions (Intel ® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Intel ® ME Firmware Version Intel ® Management Engine Firmware (Intel ® ME FW) uses built-in platform capabilities and management and security applications to remotely manage networked computing assets out-of-band.
Max Turbo Frequency Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel ® Turbo Boost Technology and, if present, Intel ® Turbo Boost Max Technology 3.0 and Intel ® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.
Intel ® HD Audio Technology Intel ® High Definition Audio (Intel ® HD Audio) is capable of playing back more channels at higher quality than previous integrated audio formats. In addition, Intel ® HD Audio has the technology needed to support the latest and greatest audio content.
Integrated Graphics Integrated graphics allow for incredible visual quality, faster graphic performance and flexible display options without the need for a separate graphics card.
Intel ® Optane™ Memory Supported Intel ® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel ® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel ® Optane™ memory requires specific hardware and software configuration.
Intel ® Platform Trust Technology (Intel ® PTT) Intel ® Platform Trust Technology (Intel ® PTT) is a platform functionality for credential storage and key management used by Windows 8* and Windows ® 10. Intel ® PTT supports BitLocker* for hard drive encryption and supports all Microsoft requirements for firmware Trusted Platform Module (fTPM) 2.0.
