All stock codes associated to this product
AT-SPSX/E, ATSPSX/E, 0767035212272
| Network |
|---|
| SFP transceiver type | Fiber optic |
| Interface type | SFP |
| Maximum data transfer rate | 1000 Mbit/s |
| Fiber optic connector | LC |
| Performance |
|---|
| Product colour | Silver |
| Housing material | Metal |
| Plug and Play | Yes |
| Hot-swap | Yes |
| SFP transceiver type | Fiber optic |
| Link budget | 9 dB |
| Interface type | SFP |
| Maximum data transfer rate | 1000 Mbit/s |
| Fiber optic connector | LC |
| Maximum transfer distance | 550 m |
| Wavelength | 850 nm |
| Tx power (min) | -9 dBmW |
| Tx power (max) | -1 dBmW |
| Multi-mode fiber (MMF) supported | Yes |
| Harmonized System (HS) code | 85369010 |
| Features |
|---|
| Product colour | Silver |
| Housing material | Metal |
| Plug and Play | Yes |
| Hot-swap | Yes |
| RX sensitivity | -18 dB |
| Operational conditions |
|---|
| Operating temperature (T-T) | -40 - 105 °C |
| Technical details |
|---|
| Harmonized System (HS) code | 85369010 |
| Packaging data |
|---|
| Number of products included | 1 pc(s) |
| Packaging content |
|---|
| Number of products included | 1 pc(s) |
| Other features |
|---|
| RX sensitivity | -18 dB |
Gigabit Small Form-Factor Pluggable Modules The Allied Telesis SP Series delivers flexible, full-duplex Ethernet connectivity. These hot-swappable fiber and copper interfaces simply plug into the SFP slot on all SFP-compatible devices. Configuration can be optimized to meet a wide variety of distance and service requirements.
Compatibility Allied Telesis SP Series Gigabit Small Form-Factor Pluggables (SFPs) are supported on all Allied Telesis devices with SFP uplink connections. SP Series SFPs are Multi-Sourcing Agreement (MSA)-compliant, and fully adhere to industry standard networking regulations. This allows the SP Series to be used with other MSA-compliant platforms that support SFP uplink connections. For Cisco compatibility please refer to the "SFP Compatibility Flyer".
Options SP Series SFPs offer short-haul, long-haul and Bi-Directional (BiDi) solutions. This flexibility allows network managers to easily extend network distance and bandwidth. Using an SFP BiDi transceiver can upgrade transmission capacity on a typical network–without installing new fibers–by utilizing a single fiber for both the send and receive signals.
Multiple temperature ranges Different network environments call for a variety of temperature ranges. The SP Series is available in standard (0-70 °C), industrial (-40 to 85 °C), and extended (-40 to 105 °C) temperature variants.
