| Ethernet LAN features |
|---|
| Cabling technology | 10/100Base-T(X) |
| Network |
|---|
| Wake-on-LAN ready | Yes |
| Short Message Service (SMS) | Yes |
| Auto MDI/MDI-X | Yes |
| Traffic control | Yes |
| Networking standards | IEEE 802.3, IEEE 802.3az, IEEE 802.3u |
| Cabling technology | 10/100Base-T(X) |
| Port forwarding | Yes |
| Static route | Yes |
| Policy-based routing | Yes |
| VLAN support | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Performance |
|---|
| Operating system installed | RutOS |
| Traffic control | Yes |
| Flash memory | 16 MB |
| Internal memory | 128 MB |
| Built-in processor | Yes |
| Processor frequency | 580 MHz |
| Firmware upgradeable | Yes |
| WAN connection |
|---|
| SFP WAN | No |
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | Yes |
| 3G/4G USB modem compatibility | No |
| Mobile network |
|---|
| Mobile network generation | 4G |
| Short Message Service (SMS) | Yes |
| 4G standard | LTE |
| Power |
|---|
| Input voltage | 42.5 - 57 V |
| Power source type | DC, PoE |
| Power over Ethernet (PoE) | Yes |
| Power consumption (typical) | 2.5 W |
| Power consumption (max) | 6 W |
| Management features |
|---|
| Wake-on-LAN ready | Yes |
| Web-based management | Yes |
| Firmware upgradeable | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| WPS push button | No |
| Ports & interfaces |
|---|
| Gigabit Ethernet (copper) ports quantity | 0 |
| Fast Ethernet (copper) ports quantity | 2 |
| Power over Ethernet (PoE) ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| Protocols |
|---|
| DHCP server | Yes |
| DHCP client | Yes |
| Management protocols | FOTA, SSH, SMS, Call, TR-069, MQTT, SNMP, JSON-RPC, RMS |
| VoIP protocols | H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets |
| Supported network protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL) |
| DMZ support | Yes |
| Security |
|---|
| Security algorithms | HTTPS |
| Firewall | Yes |
| DoS attack prevention | Yes |
| ARP attack prevention | Yes |
| Access Control List (ACL) | Yes |
| ICMP attack prevention | Yes |
| Technical details |
|---|
| Policy-based routing | Yes |
| Packaging content |
|---|
| Manual | Yes |
| Features |
|---|
| Operating system installed | RutOS |
| Flash memory | 16 MB |
| Internal memory | 128 MB |
| Built-in processor | Yes |
| Processor frequency | 580 MHz |
| Certification | CE, UKCA, EAC, UCRF, RCM |
| Design |
|---|
| Housing material | Plastic |
| Rack mounting | Yes |
| LED indicators | Status |
| Product colour | White |
| Antenna |
|---|
| Antenna type | Internal |
| Antennas quantity | 2 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions |
|---|
| Width | 100 mm |
| Depth | 235 mm |
| Height | 49.3 mm |
| Weight | 855 g |
| Packaging data |
|---|
| Manual | Yes |
| Other features |
|---|
| Input voltage | 42.5 - 57 V |
| WPS push button | No |
| Certificates |
|---|
| Certification | CE, UKCA, EAC, UCRF, RCM |
