Data transmission |
---|
IPS/IDS throughput | 1000 Mbit/s |
Maximum firewall connections per second | 6000 |
SSL inspection throughput | 300 Mbit/s |
Threat protection throughput | 750 Mbit/s |
Firewall throughput | 2 Gbit/s |
VPN throughput | 0.75 Gbit/s |
Performance |
---|
Heat dissipation | 57.42 BTU/h |
Network |
---|
VPN tunnels quantity | 50 |
Local user database | 150 |
Quality of Service (QoS) support | Yes |
Number of VLANs | 64 |
DHCP server | Yes |
Security |
---|
Firewall security | Yes |
DDoS protection | Yes |
Protocols |
---|
Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS |
Management features |
---|
LED indicators | Yes |
URL filtering | Yes |
Ports & interfaces |
---|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Connectivity technology | Wired |
Gigabit Ethernet (copper) ports quantity | 1 |
WAN connection | Ethernet (RJ-45) |
Ethernet LAN (RJ-45) ports | 8 |
Ethernet LAN data rates | 1000 Mbit/s |
Console port | RJ-45 |
Number of console ports | 1 |
Design |
---|
Form factor | Desktop |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 5 - 95% |
Features |
---|
SSL inspection throughput | 300 Mbit/s |
