Ubiquiti E7 Audience,Enterprise-grade Indoor Access Point,High-density Environments,12-stream 5 GHz and 6 GHz WiFi 7,10 GbE Uplink

IMG 1 of 1
Our Price:
$5,082.00
RRP:
$6,162.20
You Save:
$1,080.20
or quickly purchase this product
In stock for shippingShips from our warehouse in 1-3 business days
Part Number:
557720
(?) Brand:
Ubiquiti
Manuf No:
E7-Audience
E7Audience
Shipping Weight:
4.2 KG (Includes product packaging)
Estimate Shipping
Details Files Finance Images & Video
All stock codes associated to this product
E7-Audience, E7Audience, NHUE7AUDIENCE, NHU-E7-AUDIENCE

Description:
Enterprise-grade INDOOR access point designed for high-density environments with 12-stream 5 GHz and 6 GHz WiFi 7 performance, a 10 GbE uplink, and a redundant GbE port for high availability.

Features:
Indoor Only, NOT weatherproof in Australia
Dimensions
Device: 474.1 x 239.4 x 42.2 mm
Bracket: 150.4 x 113.6 x 125 mm
WiFi 7 with 6 GHz support
12 spatial streams
Real-time spectral analysis for enhanced channel selection
High selectivity PRISM RF filtering technology
Dedicated spectral analyzer radio
Selectable directional beamforming antenna (15 dBi, 50 or 11 dBi, 90) allows for cell size optimization
465+ m (5,000+ ft) open space coverage
1,500+ connected devices
(1) 10 GbE RJ45 port and (1) GbE RJ45 port for power & data redundancy
Versatile wall and pole mounting
Powered using PoE++





Dimensions
Device: 474.1 x 265.5 x 42.2 mm (18.7 x 10.5 x 1.7") Bracket: 150.4 x 113.6 x 125 mm (5.9 x 4.5 x 4.9")
WiFi Standard
WiFi 7
Spatial Streams
12
Coverage Area
465 m (5,000 ft)
Max. Client Count
1500+
Uplink
10 GbE 1 GbE
Mounting
Wall, Pole (Mounts Included) VESA (Optional)
Weatherproofing
IP68
Power Method
PoE++
MIMO
6 GHz
Low Band: 4 x 4 (DL/UL MU-MIMO) High Band: 4 x 4 (DL/UL MU-MIMO)
5 GHz
4 x 4 (DL/UL MU-MIMO)
Max. Data Rate
6 GHz
Low Band: 11.5 Gbps (BW320) High Band: 11.5 Gbps (BW320)
5 GHz
8.6 Gbps (BW240)
Antenna Gain
6 GHz
Directional internal: 15 dBi, 50 x 50 Directional internal: 11 dBi, 90 x 90
5 GHz
Directional internal: 15 dBi, 50 x 50 Directional internal: 11 dBi, 90 x 90
Max. TX Power
6 GHz
Low Band: 30 dBm (36 dBm EIRP) High Band: 30 dBm (36 dBm EIRP)
5 GHz
30 dBm
Max. BSSIDs
8 per Radio
Supported Data Rates
802.11be (WiFi 7)
7.3 Mbps to 11.5 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240/320)
802.11ax (WiFi 6)
7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
802.11ac (WiFi 5)
6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11n
6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
Wireless Meshing
Band Steering
802.11v BSS Transition Management
802.11r Fast Roaming
802.11k Radio Resource Management (RRM)
Zero-Wait DFS
Advanced Radio Management
Real-Time Spectral Analysis
Passpoint (Hotspot 2.0)
Captive Hotspot Portal
Custom Branding Landing Page
Voucher Authentication
Payment-Based Authentication
External Portal Server Support
Password Authentication
Guest Network Isolation
Private Pre-Shared Key (PPSK)
WiFi Speed Limiting
Client Device Isolation
WiFi Schedules
RADIUS over TLS (RadSec)
Dynamic RADIUS-assigned VLAN
Max. Power Consumption
51W
Supported Voltage Range
42.557V DC
Networking Interface
(1) 10 GbE RJ45 port (1) GbE RJ45 port
PRISM RF Filtering
Weight
Device: 3.3 kg (7.3 lb) With mount: 4.3 kg (9.5 lb)
Wind Loading
164.75 N at 200 km/h (37 lbf at 125 mph)
Pole Mount Diameter
13" (2576 mm)
Antennas
(1) Internal with directional patterns
Management
Ethernet
Enclosure Material
UV-stabilized polycarbonate, aluminum alloy
Mount Material
Aluminum alloy
LEDs
System
R/G/B
Channel Bandwidth
VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)
NDAA Compliant
Certifications
FCC, IC
Operating Frequency
US/CA: U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz U-NII-5 and U-NII-7: 5925 - 6425 MHz, 6525 - 6875 MHz Worldwide: 5150 - 5725 MHz 5925 - 7125 MHz
Ambient Operating Temperature
-40 to 60 C (-40 to 140 F)
Ambient Operating Humidity
5 to 95% noncondensing
Application Requirements
UniFi Network
Version 9.2.87 and later
Mobile App
iOS version 10.24.1 and later Android version 10.25.2 and later

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base
