| Coverage | 2.4 GHz: up to 2,150 ft (200 m)
5 GHz: up to 3,200 ft (300 m) |
|---|
| Wireless Standards | 5 GHz: IEEE 802.11a/n/ac/ax
2.4 GHz: IEEE 802.11b/g/n/ax |
|---|
| Frequency | 5 GHz
2.4 GHz |
|---|
| Signal Rate | 2.4 GHz: up to 573 Mbps
5 GHz: up to 1201 Mbps
*Note: Country-Specific Restriction Apply |
|---|
| Wireless Functions | Maximum number of BSSIDs: 16 (8 on each band)
Maximum number of associated STAs: 250+
Guest Network
ACS (Automatic Channel Selection)
Airtime Fairness
Band Steering
802.11 Rate Control
Rogue AP Detection
URL Filtering
WLAN Optimization
Lock to AP
SSID/Client Rate Limit
Load Balance
Seamless Roaming (802.11k/v/r, Non-Stick Roaming, Ping-Pong Roaming Suppression, AI Roaming)
Multicast/Broadcast Management (Multicast-to-Unicast Conversion, ARP-to-Unicast Conversation, Multicast Filtering, Multicast/Broadcast Rate Limit)
QoS (Quality of Service) |
|---|
| Wireless Security | ACL
MAC Filter
802.1X Authentication
MAC-Based Authentication
WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, Enhanced Open, and None
Radius Accounting
PPSK without Radius, PPSK with Radius (Generic Radius with bound MAC/EKMS/Generic Radius with unbound MAC)
Captive Portal: No Authentication, Simple Password, Hotspot (Voucher / Local User / SMS / RADIUS / Form Auth), RADIUS Server, External LDAP Server, External Portal Server, Pre-Authentication Access, and Authentication-Free Client
EAP Types: EAP-TLS, EAP-TTLS, EAP-PEAP, EAP-CHAP, EAP-SIM, EAP-AKA, EAP-GTC, EAP-FAST, EAP-PEAP, EAP-MD5, EAP-MSCHAPv2, PEAPv0, PEAPv1 |
|---|
| Transmission Power | Maximum transmit power:
CE (ERIP)
2.4 GHz: 20 dBm
5 GHz: 23 dBm in U-NII-1, 23 dBm in U-NII-2A, 29 dBm in U-NII-2C,
FCC (Conducted Power)
2.4 GHz: 25 dBm
5 GHz: 27 dBm in U-NII-1, 24 dBm in U-NII-2A, 24 dBm in U-NII-2C, 27 dBm in U-NII-3
Minimum transmit power
CE (ERIP)
2.4 GHz: 7 dBm
5 GHz: 6 dBm in U-NII-1, 6 dBm in U-NII-2A, 6 dBm in U-NII-2C, 6
dBm in U-NII-3
FCC (Conducted Power)
2.4 GHz: 4 dBm
5 GHz: 4 dBm in U-NII-1, 4 dBm in U-NII-2A, 4 dBm in U-NII-2C,
4dBm in U-NII-3
Adjustable power increment: 1 dBm
*Note: MIMO combined power, excluding antenna gains. The actual
transmit power depends on local laws and regulations |
|---|
