Asustor AS-T10G3 Dual M.2+10GbE Card, DUAL M.2 2280 NVMe , 10GbE(1), M.2 HEATSINK, 2YR

IMG 1 of 1
Our Price:
$431.20
or quickly purchase this product
Backorder
Part Number:
561864
(?) Brand:
Asustor
Manuf No:
AS-T10G3
AST10G3
Shipping Weight:
1 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video

Enter email address to be notified when this item is available again

All stock codes associated to this product
AST10G3, AS-T10G3

AS-T10G3

10GbE and M.2 NVMe SSD Composite PCIe 3.0 Network Card Designed for Expansion and Performance Improvement

  • Uses the Marvell AQC113 10GbE controller
  • Supports two M.2 NVMe SSDs
  • Supports PCIe 3.0 x4
  • Supports 10/100/1000/2500/5000/10000 Ethernet speeds
  • Supports 16K jumbo frames
  • Supports IP, TCP, UDP checksum offloading (checksum offloading), reduce CPU usage
  • Supports VLAN ID tagging and QoS
  • Uses an 8P8C RJ-45 connection for compatibility with common types of networking equipment
  • Uses heatsinks to keep performance and efficiency high
    • 10g_faster


    Hardware & Packaging

    Hardware Specifications

    • Specifications:
        • IEEE 802.3an. 10GBase-T Ethernet
        • IEEE 802.3ab 1GBASE-T Ethernet
        • IEEE 802.3u 100BASE-TX Fast Ethernet
        • IEEE 802.3bz NBASE-T
        • IEEE 802.3az Energy Efficient Ethernet
        • IEEE 802.3x flow control
        • IEEE 802.1Q Tagged VLAN support
        • IEEE 802.1Qav Audio Video Bridging
        • IEEE 1588 v2 Precision Time Protocol (PTP, Precision Time Protocol)
    • Maximum data transfer rate: 10 Gbps
    • Network operation mode: full duplex
    • Host bus interface: PCIe 3.0 x4
    • Storage interface: NVMe
    • Support size specification: 2280
    • Interface type and quantity: M-key, 2 slots
    • Bracket support: Lockerstor-specific bracket preinstalled, full-height and half-height brackets included.
    • Working temperature: 0 40C
    • Storage temperature: -20 60C
    • Relative Humidity: 5% to 95% RH
    • Certifications: FCC, CE, UKCA, BSMI, VCCI, C-Tick, KCC
    • Supported features:
        • Jumbo Frame 16K Bytes
        • IP, TCP, UDP checksum offload
        • Supports 10/100/1000/2500/5000/10000 auto-negotiation.
    • Software requirements:
        • ADM 4.2 or above
    • Hardware requirements: Lockerstor 4 & 6 Gen2, Lockerstor 4RD, RS & 12RD, Lockerstor 12RD Pro & 16RD Pro
    • Product Warranty: 2 years
    • *S3 sleep unsupported with installation of AS-T10G3
