Ruijie Reyee RG-RAP2200(F) Reyee Wi-Fi 5 1267Mbps Ceiling Access Point

IMG 1 of 3
Our Price:
$112.25
RRP:
$133.62
You Save:
$21.37
or quickly purchase this product
Backorder
Part Number:
564519
(?) Brand:
Ruijie Reyee Web Site
Manuf No:
RG-RAP2200-F
RGRAP2200F
Shipping Weight:
2 KG (Includes product packaging)
Estimate Shipping
Details Files Images & Video

Enter email address to be notified when this item is available again

All stock codes associated to this product
RGRAP2200F, RG-RAP2200-F
Features

Dual-Radio Performance, Gigabit Speed Wi-Fi Solution

InterfaceInstallation

  • 802.11ac
    Wave2

  • Seamless
    Layer 3 Roaming

  • 2x2
    MU-MIMO

  • Free Cloud
    Management

  • 802.11ac
    Wave2

  • Seamless
    Layer 3 Roaming

  • 2x2
    MU-MIMO

  • Free Cloud
    Management

Better Multi-User Experience in High-Density Scenarios

Enjoy better performance with MU-MIMO technology under 802.11ac Wave2.

One Click to Optimize, Get Better Wi-Fi Experience

The WIO (Wi-Fi Intelligent Optimization) technology allows you to optimize wireless network by one click.

Layer 3 Roaming, Smooth Transition

Roam smoothly between Layer 3 networks with non-interruption.

Easily Set Up Your Wi-Fi Network in 3 Minutes

With SON (Self-organizing Network) technology, easily set up a whole Wi-Fi network by Ruijie Cloud APP.

Cloud,
Make Your Business Easy

Self-organizing network

Centralized network management

Scenario based configuration

Cloud portal authentication

Remote monitoring and maintenance

Key Specifications
Product Information
Product Type
Product Type
  • Ceiling AP
Hardware Specifications
Wi-Fi Radio
Radio design
  • Dual-radio
    4 spatial streams
    2.4 GHz: 2 x 2, MIMO
    5 GHz: 2 x 2, MIMO
Maximum wireless data rate
  • 1266 Mbps
6 GHz wireless data rate
  • No
5 GHz wireless data rate
  • 866 Mbps
2.4 GHz wireless data rate
  • 400 Mbps
Antenna
Antenna
  • 2.4 GHz: 2 built-in omnidirectional antennas
    5 GHz: 2 built-in omnidirectional antennas
Dimensions and Weight
Product dimensions (W x D x H)
  • 194 mm x 194 mm x 35 mm (7.64 in. x 7.64 in. x 1.38 in.) (excluding the mounting bracket)
Color
  • White
Weight
  • 0.45 kg (0.99 lbs.) (without packaging materials)
Port Specifications
Number of 10/100BASE-T ports
  • 2
Power Supply and Consumption
Power supply
  • DC power adapter
    PoE/PoE+
    Note: If both the DC power adapter and PoE/PoE+ are available for power supply, the DC power adapter is preferred.
Local power supply
  • Yes, one DC power connector (12 V, 1.5 A)
Dimensions of the DC connector
  • Outer diameter: 5.5 mm (0.22 in.)
    Inner diameter: 2.1 mm (0.08 in.)
    Depth: 10 mm (0.39 in.)
PoE budget
  • No
Maximum power consumption
  • 12.95 W
Environment and Reliability
Operating temperature
  • 0C to 40C (32F to 104F)
Mounting options
  • Ceiling/Wall
IP rating
  • No
Software Specifications
WLAN
Maximum number of associated wireless clients
  • 64 (2.4 GHz)
    110 (5 GHz)
    110 (2.4 GHz and 5 GHz enabled)
Maximum number of devices that can be managed
  • 150
IP Service
IPv6
  • No
Order Information
Mounting Bracket
1
Cross Pan Head Screw2
Expansion Anchor2
Quick Start Guide1
Warranty Card1
Package Weight0.64Kg
Package Dimension (w x d x h)197 mm x 197 mm x 63 m

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers (Ruijie Reyee) web site.
