          Lens construction
  |

  |
          10 elements in 6 groups (2 ED glass elements) |



  |


          Picture angle
  |

  |
          810' [520' with Nikon digital cameras (Nikon DX format)] |



  |


          Number of diaphragm blades
  |

  |
          9 (rounded) |



  |


          Minimum f/stop
  |

  |
          32 |



  |


          Closest focusing distance
  |

  |
          1.45m |



  |


          Maximum reproduction ratio
  |

  |
          1/3.7 |



  |


          Macro focusing
  |

  |
          N/A |



  |


          Focus-limit switch:
  |

  |
          Available |



  |


          M/A mode
  |

  |
          Available |



  |


          Focus lock button
  |

  |
          Available |



  |


          Weight (approx.):
  |

  |
          1,440g (1,300g without tripod mounting foot) |



  |


          Dimensions (approx.) (from the cameras lens mounting flange)
  |

  |
          90222.5 mm |



  |


          Lens cap
  |

  |
          Snap-on |



  |


          Lens hood
  |

  |
          Built-in |



  |


          Lens case
  |

  |
          CL-M2 (supplied) |



  |


          Tripod collar
  |

  |
          Does have (rotatable) |



  |


          External front filter attachment frame
  |

  |
          Does not rotate |



  |


          External front filter
  |

  |
          77mm |



  |


          Slip-on filter
  |

  |
          N/A |



  |


          Built-in/rear filter
  |

  |
          N/A |



  |


          Circular polarizing filter
  |

  |
          Usable. |



  |


          Circular polarizing filter II
  |

  |
          Usable, even with built-in lens hood. |



  |


          TC-20E/20E II
  |

  |
          Usable, but autofocusing is not possible. |



  |


          TC-17E I
  |

  |
          Usable, but autofocusing is not possible. |



  |


          TC-14E/14E II
  |

  |
          Usable. |



  |


          AF-3
  |

  |
          Usable, but slight vignetting may occur at infinity and macro settings. (2) |



  |


          AF-4
  |

  |
          Usable. (5): ( ) Indicates maximum number of usable hoods (HN-36 for AF-3/HN-37 for AF-4). |



  |


          | Infrared compensation scale |

  |
          N/A |



  |


          Aperture ring
  |

  |
          Does have |



  |


          Distance scale
  |

  |
          Does have |



  |


          Material of bayonet ring
  |

  |
          Metal |
