Please be aware that due to the large size of many products in this cateogry (Commercial Displays) additional freight may be required after completing your order. This covers various aspects of delivery - tailgates, if you do not have a forklift attract an additional charge. Or it can simply be that our freight system for extremely large products does not cope. Where possible we do absorb these additional fees but it varies order to order as well as upon yur delivery location.
All stock codes associated to this product
LH46DECPLBC/XY, DE46C, 2318146
DE46C
Overview
Optimise The Appearance Of Your Business
Project the right message to your customers with the Samsung LFD DE Series. Designed for heavy use, this monitor is flexible and reliable enough to handle all types of presentation requirements.
Features:
Our innovative Samsung DE Series LED large format displays (LFDs) are specifically designed for continuous, high-quality content presentation. Any type of business can communicate more than just information to customers, additionally projecting a unified brand image and identity. Suitable for use in a range of demanding environments, the Samsung DE Series offers bright, high-quality monitors that are flexible and reliable enough to handle diverse media and presentation requirements at low operating costs. They are also easy to install and enjoy an eco-friendly design that omits various undesirable chemicals associated with LED technology.
Specifications:
Display
| H-Scanning Frequency |
30~81kHZ |
|
| Maximum Pixel Frequency |
148.5MHz |
|
| V-Scanning Frequency |
56~75HZ |
|
Panel
| Diagonal Size |
46" |
|
| Light Source Type |
LED |
|
| Type |
60Hz LED BLU |
|
| Resolution |
1920x1080 (16:9) |
|
| Pixel Pitch(mm) |
0.17675(H) X 0.53025(V) |
|
| Active Display Area |
1018.08(H) X 572.67(V) |
|
| Brightness |
700nit |
|
| Contrast Ratio (Dynamic) |
4000:1 |
|
| Viewing Angle (Horizontal/Vertical) |
178:178 |
|
| Response Time (G-to-G) |
8ms |
|
| Display Color |
16.7M |
|
| Color Gamut |
70% |
|
Connectivity
| Input |
RGB |
D-Sub, DVI-D, Display Port |
| |
Video |
Component(VCBS common), HDMI |
| |
Audio |
Stereo mini Jack |
| Output |
RGB |
DP(Loop-out) |
| |
Audio |
Stereo mini Jack |
| External Control |
RS-232C(In/Out) thru Stereo Jack, RJ-45 |
|
| External Sensor |
IR, Ambient Light |
|
Mechanical Specification
| Dimension |
Set Dimension (WxHxD) |
1054.5 X 608.5 X 35.1 |
| |
Package Dimension (WxHxD) |
1141.0 X 719.0 X 140.0 |
| Weight |
Set Weight |
16.4 |
| |
Package Weight |
20.1 |
| VESA Mount |
400*400mm |
|
| Stand Type |
Foot Stand(optional) |
|
| Media Player Option Type |
Embedded |
|
Operation
| Operating Temperature |
0~ 40 |
|
| Humidity |
10~80% |
|
General Feature
| Key |
Professional Heavy Usage LED LFD |
|
| Special |
Anit Reflection, Non Glossy Design, Built in MagicInfo Lite, Built in Speaker (10W + 10W), Plug and Play (through USB), Narrow Bezel, Slim Depth (35.1mm) |
|
| Internal Player |
Processor |
Cortex-A9 1GHz Dual Core CPU |
| |
On-Chip Cache Memory |
L1 (I/D) : 32KB / 32KB L2 (Unified) : 512KB |
| |
Clock Speed |
1GHz Dual |
| |
Main Memory Interface |
8Gbyte DDR3 Dual 32bit DDR3-667 (1333MHz) |
| |
Graphics |
2D & 3D Graphics Engine - Up to 1920x1080. 32bpp - Supports OpenGL ES |
| |
Storage (FDM) |
8GB (2.0GB Occupied by O/S, 6GB Available) |
| |
Multimedia |
Video Decoder - MPEG-1/2, H.264/AVC (Dual) - VC-1, JPEG, PNG Audio DSP (Decoder) - AC3 (DD), MPEG, DTS and etc. |
| |
IO Ports |
USB 2.0 * 2EA |
| |
Operating System |
Linux |
Power
| Power Supply |
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz |
|
| Power consumption |
Off Mode |
less than 1W(with Ethernet) |
| |
On Mode |
187 (Max) / 131 (Typical) / 637.67 (BTU) |
| |
Sleep Mode |
less than 1W(with Ethernet) |
| Type |
Internal |
|
Embedded PC
| CPU |
SBB or PIM Type |
|
| N/B |
SBB or PIM Type |
|
| S/B |
SBB or PIM Type |
|
| GPU |
SBB or PIM Type |
|
| FDM/HDD |
SBB or PIM Type |
|
| Memory |
SBB or PIM Type |
|
| Ethernet |
SBB or PIM Type |
|
| Connectivity |
USB |
SBB or PIM Type |
| |
Output |
SBB or PIM Type |
| |
Others |
SBB or PIM Type |
Accessory
| Optional |
Mount |
WMN4270SD, WMN250MD |
| |
Specialty |
CML450D (Ceiling Mount) |
| |
Stand |
STN-L4055AD |
