DISPLAY |
|
|
Panel
Technology |
IPS
with Edge LED backlights |
|
Screen
Size [inch/cm] |
49
/ 123.2 |
|
Aspect
Ratio |
16:09 |
|
Brightness
[cd/m] |
500 |
|
Contrast
Ratio |
8000:1
1 |
|
Viewing
Angle [] |
178
horizontal / 178 vertical (typ. at contrast ratio
10:1) |
|
Colour
Depth [bn] |
1.076
(10bit) |
|
Response
Time (typ.) [ms] |
8 |
|
Panel
Refresh Rate [Hz] |
60 |
|
Haze
Level [%] |
Pro
(28) |
|
Supported
Orientation |
Landscape;
Portrait |
|
SYNCHRONISATION
RATE |
|
|
Horizontal
Frequency [kHz] |
26
- 91.1 |
|
Vertical
Frequency [Hz] |
23
- 86 |
|
RESOLUTION |
|
|
Native
Resolution |
3840
x 2160 |
|
Supported
Resolutions |
4096
x 2160; 3840 x 2160; 2560 x 1600; 2560 x 1440; 1920 x 2160; 1920 x 1200;
1920 x 1080; 1650 x 1050; 1600 x 1200; 1440 x 900; 1400 x 1050; 1366 x
768; 1360 x 768; 1280 x 1024; 1280 x 720; 1024 x
768 |
|
CONNECTIVITY |
|
|
Input
Video Digital |
1
x DisplayPort (with HDCP); 2 x HDMI (with
HDCP) |
|
Input
Audio Digital |
1
x DisplayPort; 2 x HDMI |
|
Input
Control |
LAN
100Mbit; remote control wire (3,5mm jack);
RS232 |
|
Input
Data |
1
x USB 2.0 (MediaPlayer) |
|
Output
Audio Analogue |
1
x 3,5 mm jack |
|
Input
Detect |
Custom;
First; Last |
|
OPEN
MODULAR INTELLIGENCE |
|
|
Intel
SDM |
accepts
Intel Smart Display Modules Large and Small up to 45
W |
|
Compute
Module Slot |
RPi
Compute Module 4 |
|
SENSORS |
|
|
Ambient
Light Sensor |
Integrated,
triggered actions programmable |
|
Temperature
Sensor |
Integrated,
3 sensors, triggered actions programmable |
|
ELECTRICAL |
|
|
Power
Consumption Eco/max. [W] |
80
shipping |
|
Power
Savings Mode [W] |
<
0.5; < 2 (Networked Standby) |
|
Power
Management |
VESA
DPMS |
|
Power
Supply |
100-240
V AC; 50/60 Hz; internal |
|
ENVIRONMENTAL
CONDITIONS |
|
|
Operating
Temperature [C] |
+0
to +40 |
|
Operating
Humidity [%] |
20
to 80 |
|
Storage
Humidity [%] |
10
to 90 |
|
Storage
Temperature [C] |
-20
to 60 |
|
MECHANICAL |
|
|
Dimensions
(W x H x D) [mm] |
968.2
x 561 x 67.1 |
|
Weight
[kg] |
17.8 |
|
Bezel
Width [mm] |
11
(left, right and top); 15.6 (bottom) |
|
VESA
Mounting [mm] |
300
x 300 (FDMI); 4 holes; M6 |
|
Ingress
Protection |
IP5x
(front); IP2x (back) |
|
Packaging
Dimensions (W x H x D) [mm] |
1,120
x 700 x 203 |
|
Packaging
Weight [kg] |
23 |
|
Colour
Bezel |
Pantone
426M (black) |
|
Material |
Metal |
|
MEDIAPLAYER |
|
|
Supported
File Storage / File System |
USB
2.0 / FAT16, FAT32 |
|
Supported
Image Formats |
JPG
(baseline, progressive, RGB, CMYK); max. resolution 15360 x
8640 |
|
Supported
Video Formats |
MPG
(MPEG1/2/4, max res 1080p@30Hz); MP4 (MPEG2/4, H.263, H.264, HEVC/H.265,
max res 3840x2160@60Hz); TS (MPEG2, H.264, HEVC/H.265, max res
3840x2160@60Hz); audio: LPCM, MP3, AAC; WMV (video H.264, Windows Media
Video 9, max res 1080p@30Hz, audio WMA 9, WMA 10
Pro) |
|
Supported
Audio Formats |
MP3
(MP3); max. bit-rate 320 kBit/s |
|
AVAILABLE
OPTIONS |
|
|
Accessories |
Feet
(ST-401/ST-43M); Soundbar (active: SP-ASCM-IQ2 / SP-ASCM-2); Speaker
(SP-RM3a); Trolley (PDMHM-L); Wall mount (PDW C L and P, PD02W T M L,
PD03W T M P) |
|
GREEN
FEATURES |
|
|
Energy
Efficiency |
Energy
consumption: 68 kWh/1000 h; Energy efficiency class: G; LED
backlight |
|
Ecological
Standards |
EnergyStar
8.0 |
|
ADDITIONAL
FEATURES |
|
|
Special
Characteristics |
DICOM
Simulation; HDMI ARC; Powered USB Port (10 W); Removable
Logo |
|
Safety
and Ergonomics |
Energy
Star 8.0 |
|
Pixel
Failure Class |
ISO
9241-307, Class 1 |
|
Audio |
Integrated
Speakers (10 W + 10 W) |
|
Shipping
Content |
2x
AAA batteries; Display; HDMI Cable; Power Cable; Remote Control; Setup
Manual |
|
Warranty |
3
years warranty incl. backlight; additional services available; optional 4.
+ 5. year warranty extension 2 |
|
Operating
Hours |
24/7 |
|
External
Control |
AMX
NetLinx Support; ASCII Control Commands; HDMI CEC; HTTP Browser; PJLink;
Scheduled Timer; SNMP |
|
Remote
Management |
Automated
Email Alerts; NEC NaViSet Administrator 2 |
|
Security |
Disable
HW Buttons; Disable IR Functionality; Emergency
Notification |
|
Resistance
to Fire |
Metal
backcover, plastic material certified acc. to
UL94-5VB |
