| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| PTZ modes | Auto scan |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Design |
|---|
| Form factor | Dome |
| Product colour | Black, White |
| Mounting type | Ceiling |
| International Protection (IP) code | IP66 |
| Camera |
|---|
| Pan preset speed | 80 °/sec |
| Minimum illumination | 0.001 lx |
| Tilt speed | 80 °/sec |
| Pan speed | 80 °/sec |
| White balance | ATW, Auto, Indoor, Lamp, Manual, Outdoor, Sodium lamp |
| Camera shutter speed | 1/30000 s |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Lens system |
|---|
| Optical zoom | 15x |
| Digital zoom | 16x |
| Focal length range | 5 - 75 mm |
| Video |
|---|
| Privacy masking | Yes |
| Highlight Compensation (HLC) | Yes |
| Back Light Compensation (BLC) | Yes |
| Maximum resolution | 1920 x 1080 pixels |
| Video formats supported | H.264, H.264+, H.265, H.265+ |
| Supported graphics resolutions | 352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Network |
|---|
| Bluetooth | No |
| Networking standards | IEEE 802.3at |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Cabling technology | 10/100Base-T(X) |
| Supported network protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| Storage |
|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Maximum memory card size | 128 GB |
| Ports & interfaces |
|---|
| Interface | RJ-45 |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Security algorithms | HTTPS |
| HTTPS encryption | Yes |
| Management features |
|---|
| Web browser | Yes |
| Power |
|---|
| Power source type | DC |
| Power consumption (max) | 18 W |
| DC output voltage | 12 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 65 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Weight & dimensions |
|---|
| Width | 166 mm |
| Height | 290 mm |
| Weight | 2 kg |
| Packaging content |
|---|
| Number of cameras | 1 |
| Quick installation guide | Yes |
| Other features |
|---|
| Video compression formats | H.264, H.264+, H.265, H.265+ |
