| Display |
|---|
| LED backlight | Yes |
| Display number of colours | 1.06 billion colours |
| Display diagonal | 163.8 cm (64.5") |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| HD type | 4K Ultra HD |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 50000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Active display area (W x H) | 1428.4 x 803.5 mm |
| Display diagonal (metric) | 163.8 cm |
| Panel life | 50000 h |
| Panel type | ADS |
| Native aspect ratio | 16:9 |
| LED backlighting type | Direct-LED |
| Display technology | LED |
| Anti-glare screen | Yes |
| Haze rate | 25% |
| Ports & interfaces |
|---|
| USB connector type | USB Type-A, USB Type-C |
| Mini VGA (D-Sub) input ports | 1 |
| Ethernet LAN | Yes |
| HDMI ports quantity | 3 |
| USB port | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| VGA (D-Sub) input ports | 1 |
| Audio (L/R) in | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity | 3 |
| RS-232C | Yes |
| HDMI input ports quantity | 3 |
| SDM module slot | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB Power Delivery | Yes |
| USB Power Delivery up to | 60 W |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Audio |
|---|
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Built-in speaker(s) | Yes |
| Design |
|---|
| Product design | Digital signage flat panel |
| Product colour | Black |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Panel mounting interface | 400 x 400 mm |
| Bezel width (top) | 1.49 cm |
| Bezel width (side) | 1.49 cm |
| Bezel width (bottom) | 1.49 cm |
| VESA mounting | Yes |
| Anti-glare screen | Yes |
| Wall mountable | Yes |
| Performance |
|---|
| Purpose | Universal |
| Operating hours (hours/days) | 18/7 |
| HDCP | Yes |
| HDCP version | 2.2 |
| Panel life | 50000 h |
| Power |
|---|
| Power consumption (typical) | 340 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 110 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (off) | 0.3 W |
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | G |
| Energy consumption (SDR) per 1000 hours | 226 kWh |
| Weight & dimensions |
|---|
| Display width | 1463 mm |
| Display depth | 94 mm |
| Display height | 838 mm |
| Display weight | 29.7 kg |
| Packaging data |
|---|
| Package width | 1616 mm |
| Package depth | 197 mm |
| Package height | 998 mm |
| Package weight | 40 kg |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Operating altitude | 0 - 2800 m |
| Technical details |
|---|
| VESA mounting | Yes |
| USB connector type | USB Type-A, USB Type-C |
| Panel type | ADS |
| LED backlighting type | Direct-LED |
| Audio out (mini jack) | 1 |
| Features |
|---|
| Base colour | Black |
| Base material | Metal |
| Wall mountable | Yes |
| Other features |
|---|
| USB connector type | USB Type-A, USB Type-C |
| Mini VGA (D-Sub) input ports | 1 |
| Panel type | ADS |
| Operating altitude | 0 - 2800 m |
| Display technology | LED |
| Bezel width (top) | 1.49 cm |
| Bezel width (side) | 1.49 cm |
| Bezel width (bottom) | 1.49 cm |
| Audio output | Stereo Mini Jack |
| Energy efficiency scale | A to G |
