| Performance |
|---|
| Auto patrol mode | Yes |
| Preset points | Yes |
| Infrared (IR) cut-off filter | Yes |
| PTZ modes | 4 Pattern, Auto scan |
| Fog proof | Yes |
| Built-in heater | Yes |
| Type | IP security camera |
| Connectivity technology | Wired & Wireless |
| PTZ control | Yes |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| PTZ status display | Yes |
| Preset freezing function | Yes |
| Design |
|---|
| Fog proof | Yes |
| Form factor | Dome |
| Product colour | White |
| Mounting type | Wall/Pole |
| Protection features | Drop resistant, Water resistant |
| International Protection (IP) code | IP66 |
| Housing material | Metal |
| Camera |
|---|
| Tilt preset speed | 80 °/sec |
| Pan preset speed | 120 °/sec |
| Minimum illumination | 0.05 lx |
| Tilt angle range | -15 - 90° |
| Pan range | 0 - 360° |
| White balance | ATW, Auto, Fluorescent, Indoor, Locked WB, MWB, Outdoor, Sodium lamp |
| Camera shutter speed | 1 - 1/30000 s |
| Camera pan control | Yes |
| Lens viewing angle, horizontal | 55 - 2.4° |
| Lens viewing angle, vertical | 33 - 1.4° |
| Lens viewing angle, diagonal | 61.5 - 2.8° |
| Tilt manual speed | 0.1 - 80 °/sec |
| Pan manual speed | 0.1 - 120 °/sec |
| Number of Privacy masking areas | 24 |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 1.6 |
| Auto focus | Yes |
| Focus | Motorized/Manual |
| Zoom capability | Yes |
| Optical zoom | 25x |
| Digital zoom | 16x |
| Focal length range | 4.8 - 120 mm |
| Zoom speed | 3.6 s |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 150 m |
| LED type | IR |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Maximum resolution | 2560 x 1440 pixels |
| Supported graphics resolutions | 352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 960, 1920 x 1080 (HD 1080), 2560 x 1440 |
| Video compression formats | H.264, H.265, M-JPEG |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 4 MP |
| Video recording | Yes |
| 3D positioning | Yes |
| Audio |
|---|
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Audio formats supported | AAC-LC, G.711, G.722.1, G.726, MP2L2, MP3, PCM |
| Sample rates | 8 - 48 kHz |
| Bit rate range | 8 - 320 Kbit/s |
| Network |
|---|
| Bluetooth | No |
| 4G standard | LTE-TDD & LTE-FDD |
| Ethernet interface type | Fast Ethernet |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Supported network protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, Bonjour, WebSocket, WebSockets |
| 2G standards | Edge, GPRS |
| 3G standards | HSPA+, WCDMA |
| Mobile network generation | 4G |
| Mobile network connection | Yes |
| Storage |
|---|
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Built-in HDD | No |
| Maximum memory card size | 256 GB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired & Wireless |
| Security |
|---|
| Privacy protection | Yes |
| Intelligent Video Surveillance (IVS) system features | Face detection, Intrusion, Line crossing detection, Region entrance detection, Region exiting detection |
| Video motion detection | Yes |
| Active tampering alarm | Yes |
| Automatic Network Replenishment (ANR) | Yes |
| Alarm input channels | 2 |
| Network access storage (NAS) | Yes |
| Management features |
|---|
| Management software | iVMS-4200 |
| Web-based management | Yes |
| Reset button | Yes |
| Behavior analysis | Audio exception detection, Object removal detection, Unattended baggage detection |
| Power |
|---|
| Power source type | Battery, DC, Solar |
| Battery voltage | 10.8 V |
| Battery technology | Lithium |
| Battery capacity | 360 Wh |
| Power consumption (typical) | 20 W |
| DC output voltage | 12 |
| Standby time | 80 day(s) |
| Battery |
|---|
| Battery voltage | 10.8 V |
| Battery technology | Lithium |
| Battery capacity | 360 Wh |
| Battery weight | 2.74 kg |
| Operational conditions |
|---|
| Operating temperature (T-T) | -20 - 45 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Weight & dimensions |
|---|
| Package type | Box |
| Height | 344.8 mm |
| Diameter | 20.8 cm |
| Weight | 3.5 kg |
| Packaging data |
|---|
| Package type | Box |
| Packaging content |
|---|
| Number of cameras | 1 |
| Package type | Box |
| Battery included | Yes |
| Other features |
|---|
| Focus | Motorized/Manual |
| Video compression formats | H.264, H.265, M-JPEG |
| Browser supported | Chrome 57+, Firefox 52+, Safari 12+, IE10-11 |
