| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 11 |
| Languages support | Multi |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Cable length | 0.5 m |
| Dynamic range | 120 dB |
| Design |
|---|
| IK code | IK10 |
| Form factor | Dome |
| Product colour | White |
| Protection features | Dust resistant, Vandal proof, Water resistant |
| International Protection (IP) code | IP67 |
| Housing material | Metal |
| Camera |
|---|
| Minimum illumination | 0.01 lx |
| Tilt angle range | 0 - 75° |
| Pan range | -30 - 30° |
| White balance | Auto, Fluorescent, Incandescent, Manual, Natural |
| Angle of rotation | 360° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Lens viewing angle, horizontal | 132° |
| Lens viewing angle, vertical | 77° |
| Lens viewing angle, diagonal | 152° |
| Number of Privacy masking areas | 4 |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 2.25 |
| Focus | Manual |
| Fixed focal length | 2 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 10 m |
| LED type | IR/White |
| Infra-red wavelength | 850 nm |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Bit rate | 256 Kbps - 16 Mbps |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Maximum resolution | 1920 x 1080 pixels |
| Supported graphics resolutions | 320 x 240, 352 x 288, 640 x 480 (VGA), 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 2 MP |
| Audio |
|---|
| Signal-to-Noise Ratio (SNR) | 50 dB |
| Built-in microphone | Yes |
| Audio formats supported | AAC, G.711 A-law, G.711u, G.722, G.726, PCM |
| Network |
|---|
| Bluetooth | No |
| Networking standards | IEEE 802.3af |
| Number of users | 16 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, Email ,RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, ICMP 802.1X, QoS, IPv6, Bonjour, ISUP5.0 |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 8 channels |
| Live view | Yes |
| Storage |
|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Built-in HDD | No |
| Maximum memory card size | 256 GB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Privacy protection | Yes |
| Video motion detection | Yes |
| Active tampering alarm | Yes |
| Mirror | Yes |
| Heartbeat | Yes |
| Anti-flicker | Yes |
| Network access storage (NAS) | Yes |
| Management features |
|---|
| Web-based management | Yes |
| Reset button | Yes |
| Behavior analysis | Intrusion detection, Line crossing detection, Object removal detection, Region entrance detection, Region exiting detection, Scene change detection, Unattended baggage detection |
| Software reset | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (Power over Ethernet (PoE)) | 7.5 W |
| Power consumption (max) | 7.5 W |
| DC output voltage | 9, 36 |
| DC output current | 0.83 A |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 75 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Height | 57.4 mm |
| Diameter | 11 cm |
| Weight | 452 g |
| Cable length | 0.5 m |
| Package width | 252 mm |
| Package depth | 160 mm |
| Package height | 95 mm |
| Packaging data |
|---|
| Package width | 252 mm |
| Package depth | 160 mm |
| Package height | 95 mm |
| Sustainability |
|---|
| Sustainability compliance | Yes |
| Compliance certificates | CB, CE, Electromagnetic Compatibility (EMC), Federal Communications Commission (FCC), Low Voltage Directive (LVD), RoHS, UL |
| Packaging content |
|---|
| Number of cameras | 1 |
| Technical details |
|---|
| Lens mount interface | M12 |
| Number of video streams | 3 |
| Sustainability compliance | Yes |
| Compliance certificates | CB, CE, Electromagnetic Compatibility (EMC), Federal Communications Commission (FCC), Low Voltage Directive (LVD), RoHS, UL |
| Other features |
|---|
| Focus | Manual |
| Video compression formats | H.264, H.264+, H.265, H.265+, M-JPEG |
