| Performance |
|---|
| Number of languages | 33 |
| Languages support | Multi |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Built-in light | Yes |
| Dynamic range | 130 dB |
| Design |
|---|
| Form factor | Bullet |
| Product colour | White |
| Mounting type | Wall |
| International Protection (IP) code | IP67 |
| Housing material | Metal |
| Camera |
|---|
| Minimum illumination | 0 lx |
| Tilt angle range | 0 - 90° |
| Pan range | 0 - 360° |
| Angle of rotation | 360° |
| Camera shutter speed | 1 - 1/100000 s |
| Lens viewing angle, horizontal | 93.3° |
| Lens viewing angle, vertical | 47.2° |
| Lens viewing angle, diagonal | 114.2° |
| Number of Privacy masking areas | 4 |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Number of sensors | 1 |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 1 |
| Detect distance | 109 m |
| Observe distance | 43 m |
| Recognize distance | 21 m |
| Identify distance | 10 m |
| Fixed focal length | 4 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 40 m |
| LED type | IR/White |
| Infra-red wavelength | 850 nm |
| Video |
|---|
| Noise reduction | Yes |
| Smart IR | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Bit rate | 32 Kbps to 8 Mbps |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Maximum resolution | 3840 x 2160 pixels |
| Video formats supported | H.264, H.264+, H.265, H.265+ |
| Supported graphics resolutions | 3840 x 2160 |
| Supported video modes | 2160p |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Video streaming | Yes |
| Total megapixels | 8 MP |
| Video recording | Yes |
| Audio |
|---|
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Built-in speaker(s) | Yes |
| Audio formats supported | G.711 A-law, G.711 μ-law, G.722.1, MP2L2, G.726, MP3, AAC-LC |
| Sample rates | 8 - 48 kHz |
| Bit rate range | 8 - 380 Kbit/s |
| Number of microphones | 2 |
| Network |
|---|
| Bluetooth | No |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 6 channels |
| Live view | Yes |
| Storage |
|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Built-in HDD | No |
| Maximum memory card size | 512 GB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Privacy protection | Yes |
| Video motion detection | Yes |
| Mirror | Yes |
| Heartbeat | Yes |
| Anti-flicker | Yes |
| Pixel counter | Yes |
| Password reset via email | Yes |
| Human and vehicle targets classification | Yes |
| Flash log | Yes |
| Digest authentication | Yes |
| Automatic Network Replenishment (ANR) | Yes |
| Audit log | Yes |
| Network access storage (NAS) | Yes |
| Management features |
|---|
| Cloud-managed | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (Power over Ethernet (PoE)) | 18 W |
| Power consumption (max) | 15 W |
| DC output voltage | 12 |
| DC output current | 1.25 A |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Diameter | 7.44 cm |
| Length | 176.3 mm |
| Weight | 530 g |
| Package width | 234 mm |
| Package depth | 120 mm |
| Package height | 117 mm |
| Package weight | 815 g |
| Packaging data |
|---|
| Package width | 234 mm |
| Package depth | 120 mm |
| Package height | 117 mm |
| Package weight | 815 g |
| Packaging content |
|---|
| Number of cameras | 1 |
| Manual | Yes |
| Other features |
|---|
| Video compression formats | H.264, H.264+, H.265, H.265+ |
