UPA2015 | Sunix USB 3.2 Gen2 10G & DisplayPort Alt-Mode PCI Express

UPA2015
USB 3.2 Gen2 10G &DisplayPort Alt-Mode PCI Express Host Card with Dual USB-C Receptacles

    PCI Express Base Specification Revision 3.0 two-lane (x2).
    Expands dual external USB3.2 Gen2 Super-Speed plus Type-C port (DFP) on the system.
    Compliant with Universal Serial Bus 3.2 specification Gen2.
    Compliant with xHCI (eXtensible Host Controller Interface) specifications Revision 1.1.
    Supports simultaneous operation of multiple USB 3.2 Gen2/Gen1, USB 2.0 and USB 1.1 devices
    Supports USB data transfer rate of 10G/5G/480/12/1.5 Mbps.
    Independent 10G USB PHY for each USB Type-C port.
    USB port supplies +5VDC / 1.5A power output to USB device with over current protection.
    Compliant with DisplayPort 1.4 spec with HDTV 4K (2160p) resolution and stereoscopic 3D.
    One USB-C compliant with VESA DisplayPort Alternate Mode for USB Type-C Standard Rev1.0.
    Hot-swapping feature allows connect/disconnect device without powering down the system.
    Driver supports for Microsoft Windows 8.x, 10 and 11 operation systems.
    Certified by Electromagnetic Compatibility (CE, FCC, VCCI, BSMI) and RoHS approval.


[ NOTICE ]

1. UPA2015 Does NOT apply to PCIE X1 slot.
2. UPA2015 Does NOT support USB Power Delivery (PD).
3. UPA2015 Is Not compatible with Thunderbolt 3/4 devices..
4. Confirm your device's USB-C port supports DP Alt Mode.

SUNIX UPA2015 is a Dual-port Super-Speed+ USB3.2 Gen2 10G PCI Express add-on card, and it’s compliant with the PCI Express Gen3 specification for host PC system. Based on USB Type-C pure DFP (Downstream Facing Port) mode, it works up to 10 Gbps for data transfer when connecting to USB 3.2 Gen2 compliant peripherals, while maintaining compatibility with existing USB peripheral devices. USB3.2 Gen2 performance is 2 times faster than USB3.2 Gen1 and 20 times faster than USB2.0 connectivity. In additional, one USB Type-C port supports DisplayPort Alternate-mode for video output, and the other is an USB data-only port

With USB Type-C Receptacle, SUNIX UPA2015 supports reversible plug orientation and cable direction, which means that users will no longer need to be concerned with plug orientation/cable direction, making it easier to plug in. The new connector is smaller and thinner design, but drive higher power output capacity to USB device. SUNIX UPA2015 supports 5VDC@1500mA power output to USB device with over current protection on each USB port. This card is an ideal choice for external storage, smart phone, webcam, video devices, and all other USB electronic devices.
