GENERAL |
|
|
Phase |
Single
Phase |
|
UPS
Topology |
Line-interactive |
|
Energy
Saving Technology |
GreenPower
UPSâ„¢ Bypass Technology |
|
Energy
Star Qualified |
Yes |
|
Active
PFC Compatibility |
Yes |
|
INPUT |
|
|
Generator
Compatibility |
Yes |
|
Nominal
Input Voltage ( Vac ) |
220 |
|
|
230 |
|
|
240 |
|
Input
Voltage Range ( Vac ) |
159
~ 288 |
|
Adjustable
Voltage Range ( Vac ) |
151
~ 302 Vac |
|
Input
Frequency ( Hz ) |
|
|
50
± 3 |
60
± 3 |
|
Input
Frequency Detection |
Auto-sensing |
|
Input
Connector Type |
IEC
C14  |
|
Detachable
Power Cord Plug Type |
AU
 |
|
Power
Cord Length (ft.) |
10 |
|
Power
Cord Length (m.) |
2.4 |
|
OUTPUT |
|
|
Capacity
(VA) |
1000 |
|
Capacity
(Watts) |
1000 |
|
On
Battery Waveform |
Pure
Sine Wave |
|
On
Battery Voltage(s) ( Vac ) |
220
± 5% |
|
|
230
± 5% |
|
|
240
± 5% |
|
On
Battery Frequency ( Hz ) |
50
± 1% |
|
|
60
± 1% |
|
Power
Factor |
1 |
|
Automatic
Voltage Regulation (AVR) |
Double
Boost, Single Buck |
|
Overload
Protection |
Internal
Current Limiting , Circuit Breaker |
|
Outlet(s)
- Total |
10 |
|
Outlet
Type |
IEC
C13 x 10 |
|
Outlet(s)
- Battery & Surge Protected |
10 |
|
Outlet(s)
- Critical Load (CL) |
5 |
|
Outlet(s)
- Non-Critical Load (NCL) |
5 |
|
Typical
Transfer Time ( ms ) |
4 |
|
BATTERY |
|
|
Runtime
at Half Load ( min ) |
21 |
|
Runtime
at Full Load ( min ) |
7 |
|
Typical
Recharge Time ( Hours ) |
3 |
|
Start
On Battery |
Yes |
|
Built-in
Battery Management Module |
Yes |
|
User-replaceable |
Yes |
|
Hot-swappable |
Yes |
|
Battery
Type |
Sealed
Lead-acid |
|
Battery
Cartridge |
RBP0128 |
|
RBP
Quantity ( pcs ) |
1 |
|
SURGE
PROTECTION & FILTERING |
|
|
Surge
Suppression ( Joules ) |
2430 |
|
EMI/RFI
Filtration |
Yes |
|
Network
Protection RJ45 |
1-in,
1-out |
|
MANAGEMENT
& COMMUNICATIONS |
|
|
LCD
Panel |
Yes |
|
LCD
Orientation |
Rotatable
LCD panel |
|
LCD
Information Display |
Operation
Type , Power Status , Battery Status , Load Status , Fault & Warning ,
Other Information , Event & Log |
|
LCD
Setting & Control |
Mode
Setting , Alarm Setting , Input & Output , Battery Setting ,
Communication , Language |
|
LED
Indicators |
Power
On , Line Mode , Battery Mode , UPS Fault , Night
Mode |
|
HID
Compliant USB Port(s) |
1 |
|
Serial
Port |
RS232 |
|
Dry
Contact (with Relay) |
Yes |
|
Emergency
Power Off (EPO) Port |
Yes |
|
Audible
Alarms |
Battery
Mode , Low Battery , Overload , Overcharge , Overheat |
|
Management
Cable ( pcs ) |
USB
Cable x1 , Serial Cable x1 , EPO Cable x1 |
|
Power
Management Software |
PowerPanel®
Business |
|
SNMP/HTTP
Remote Monitoring |
Yes
- with optional RMCARD205 |
|
PHYSICAL |
|
|
Form
Factor |
Rack/Tower |
|
Enclosure
Construction |
Metal |
|
Color |
Black |
|
Rackmount
Rail |
Yes |
|
Rackmount
Ears |
Yes |
|
PHYSICAL
SIZE - UPS MODULE |
|
|
Dimensions
(WxHxD) (in.) |
17.1
x 3.4 x 16.2 |
|
Dimensions
(WxHxD) (mm.) |
433
x 86.5 x 412 |
|
Weight
(lbs.) |
49.4 |
|
Weight
(kg.) |
22.4 |
|
Installed
Rack Height ( U ) |
2 |
|
SHIPPING
DIMENSIONS |
|
|
Dimensions
(WxHxD) (in.) |
22.1
x 10.8 x 20.9 |
|
Dimensions
(WxHxD) (mm.) |
560
x 275 x 530 |
|
Weight
(lbs.) |
63.9 |
|
Weight
(kg.) |
29 |
|
ENVIRONMENTAL |
|
|
Operating
Temperature (°F) |
32
~ 104 |
|
Operating
Temperature (°C) |
0
~ 40 |
|
Operating
Relative Humidity (Non-condensing) ( % ) |
0
~ 95 |
|
Operating
Elevation ( feet/meters ) |
0-10,000
feet (0-3,000 meters) |
|
Storage
Temperature (°F) |
5
~ 113 |
|
Storage
Temperature (°C) |
-15
~ 45 |
|
Storage
Relative Humidity (Non-condensing) ( % ) |
0
~ 95 |
|
Storage
Elevation ( feet/meters ) |
0-50,000
feet (0-15,000 meters) |
|
Online
Thermal Dissipation ( BTU/hr ) |
47.4 |
|
Audible
Noise at 1.0M from Surface of Unit ( dBA ) |
52.5 |
|
CERTIFICATIONS |
|
|
Certifications |
CE
, FCC Class B , UL , CISPR 22 Class B , RCM , VCCI |
|
RoHS |
Yes |
